Rail Track Scale
Modular Design of scale allows weighing of a wide range of rail cars
Description
The B-TEK Rail Scale can weigh a variety of car sizes efficiently without compromising accuracy. This scale is ideal for bulk cement, aggregate, grain, scrap metal and chemical applications. Sectional Capacity: NTEP rated at 170,000 lb Modular Design of scale allows weighing of a wide range of rail cars Foundation anchor bolts and grout plates included Anti-creep devices included for rail on scale and approaches 360° positive self-checking eliminates the need for flexure plates or adjustable check rods NTEP-approved, environmentally-protected load cells NEMA 4X junction boxes are supplied Weighbridge design meets AAR (Association of American Railroads) and AREMA (American Railway Engineering and Maintenance-of-Way Association) standards.
Specifications
- Sectional Capacity is NTEP rated at 170,000 lb
- Modular Design of scale allows weighing of a wide range of rail cars
- Gross capacity is certified at 400,000 lb in 50 lb graduations
- Foundation anchor bolts and grout plates included
- Anti-creep devices included for rail on scale and approaches
- 360° positive self-checking eliminates the need for flexure plates or adjustable check rods
- NTEP-approved, environmentally-protected load cells
- NEMA 4X junction boxes are standard
- Weighbridge design meets AAR (Association of American Railroads) and AREMA (American Railway Engineering and Maintenance-of-Way Association) standards
